SAFETY MANUAL SIL KFD2-UT2-(EX)*, HID2082
Introduction
2011-09
5
KFD2-UT2-* (Non-Ex devices)
This signal conditioner is designed to connect RTDs, thermocouples, or
potentiometers, and provide a proportional 0/4 mA ... 20 mA (0/1 V ... 5 V) signal.
The barrier offers 3-port isolation between input, output, and power supply.
A removable terminal block K-CJC-** is available for thermocouples when internal
cold junction compensation is desired.
A fault is indicated by a red flashing LED per NAMUR NE44 and user-configured
fault outputs.
The device is easily programmed with the PACTware
TM
configuration software.
A collective error messaging feature is available when used with the Power Rail
system.
For additional information, refer to the manual and www.pepperl-fuchs.com.
HiD2082
This isolated barrier is used for intrinsic safety applications.
It is a universal temperature converter that accepts thermocouples (TC), millivolts,
potentiometers, or resistance temperature detectors (RTD) from a hazardous area
and converts them to an isolated, linearized analog output in the safe area.
The outputs can be selected as a current source, current sink, or voltage source
with DIP switches on the side panel.
Line fault detection of the field circuit is indicated by a red LED and an output on
the fault bus. The fault conditions are monitored via a Fault Indication Board.
The device is easily programmed by the use of a DIP switches on the side of the
unit and with the PACTware
TM
configuration software.
This module mounts on a HiD Termination Board.
1.3 Manufacturer Information
Pepperl+Fuchs GmbH
Lilienthalstrasse 200
68307 Mannheim/Germany
KFD2-UT2-(Ex)*, HiD2082
Up to SIL2
