KFU8-DW-1.D
Product Description
129506 2012-12
13
The device comprises 3 galvanically isolated circuits:
■ 230 V, 115 V voltage supply circuit, connections 16, 17, 18
■ Signal circuit
■ 24 V voltage supply, connections 4, 5
■ Sensor/signal, connections 1, 2, 3, 7, 8, 9, 13, 14, 15
■ Relay output circuit, connections 10, 11, 12
Note!
All currently available two, three or four-wire proximity switches and
incremental rotary encoders are acceptable as sensors. Moreover,
two terminals are reserved for the connection of proximity switches as
per DIN 19234 (NAMUR).
Caution!
Insulation co-ordinates for specifying data on galvanic/electrical
isolation are in accordance with DIN EN 50178:
The KFU8-DW-1.D device is intended for use in enclosed electrical
operating areas, to which only competent electrical personnel or
properly instructed electrotechnical personnel have access or entry.
The device is designed for use in degree of pollution 2 and surge
category II as per EN 50178.
