Pepperl+Fuchs KFU8-DW-1.D User Manual

KFU8-DW-1.D
Appendix
129506 2012-12
33
7.2 Terminal assignment
Term. 1:Sensor power supply GND Term. 10: Relay, normally open contact NO
Te r m. 2 : Tr i g g e r in p ut fo r s ta r t u p
override
Term. 11: Relay, normally closed
contact NC
Te r m. 3 :
Sensor power supply +24 V
DC
Term. 12: Relay root COM
Term. 4:Power supply + 24 V
DC
Term. 13: Sensor power supply GND
Term. 5:Power supply GND Term. 14: NPN input - (cathode)
Term. 6:Not connected Term. 15: PNP input + (anode)
Te r m. 7 :
Sensor power supply + 24 V
DC
Term. 16: Power supply L1, 230 V
AC
Term. 8:NAMUR input L - Term. 17: Power supply L1, 115 V
AC
Term. 9:NAMUR input L + Term. 18: Power supply N, AC
