KFU8-DW-1.D
Operation
129506 2012-12
19
By programming the pulse divider to 10 pulses/revolution, the display
would indicate the actual drive speed of 450 rpm.
Display and measurement range
(factory preset: 0 ... 999,9)
Four measuring and display ranges are available for frequency
measurement and three measuring and display ranges are available
for speed measurement:
Example:
The maximum permissible rotational speed of the drive is 600.5 rpm.
The first two measuring ranges can be selected. However, in order to
fully utilize the accuracy of the display, it is recommended that the
second measuring range be used.
Display in
parameter
editor
Frequency
range in Hz
Speed range in
rpm
Number of
decimal places
0000 0 ... 9999 0
000.1 0,0 ... 999,9 1
00.02 0,0 ... 99,99 2
0.003 0,0 ... 9,999 ---- 3
