KFU8-DW-1.D
Appendix
Sensor supply voltage 19 ... 28 V
DC
not stabilized; 30 mA short-circuit
proof
Switching point high: 16 ... 30 V
DC
; max. 10 mA by way of an
integral voltage current sink; R
i
 3k
low: 0 ... 6 V
DC
Input frequency 0,002 ... 40000 Hz, puls pause/duration:  12 s
Input 3
Startup override Triggered by an external signal 16 ... 30 V (Term.
1-, Term. 2+) or by switching on bridge terminal
2/3
or by switching on the supply voltage (Term. 2
and Term. 3 continuously bridged)
Bridging delay 0,1 ... 999.9 s (external triggering signal)
Output
Relay 1 changeover contact NO (Term. 10), NC (Term.
11), COM (Term. 12)
Contact loading 250 V
AC
/ 2 A / cos?  0.7
40 V
DC
/ 2 A
Delay  20 ms (inc. computing time)
Input 2
