Pepwave MAX and Surf User Manual
http://www.pepwave.com 12 Copyright @ 2016 Pepwave
4.1.2 LED Indicators
T
he statuses indicated by the front panel LEDs are as follows:
Status Indicators
Status
OFF System initializing
Red Booting up or busy
Blinking
red
Boot up error
Green Ready
Wi-Fi AP and Wi-Fi WAN Indicators
Wi-Fi WAN
OFF Disconnected
Blinking slowly Connecting to network
Blinking Connected to network with traffic
ON Connected to network without traffic
Wi-Fi AP
OFF Disabled
Blinking slowly Enabled but no client connected
Blinking Connected to network with traffic
ON Client(s) connected to wireless network
LAN and Ethernet WAN Ports
Green LED ON 10 / 100/ 1000 Mbps
Orange LED
Blinking Data is transferring
OFF
No data is being transferred or port is not
connected
Port Type Auto MDI/MDI-X ports
