Percussionaire Phasitron - Page 4

4 PERCUSSIONAIRE
®
Remove tubing from the
Percussionaire® controller
device:
1. Disconnect white, yellow,
red and green tubing
connectors from device.
Figure 1
2. Green and red tubing
connectors may not be
available. Figure 2,2a
2a
2
1
Before cleaning or disinfection, the tubing harness must be removed from the
controller device, Phasitron® and nebulizer.
NOTE
