Institutional & Homecare Cleaning Manual Phasitron® & Nebulizer 5
Remove tubing from the
Phasitron® and Nebulizer:
1. Remove the yellow tube
quick-connector from the
nebulizer bowl. Figure 3
2. Mark the filter (if present) to
show the direction of flow
towards the Phasitron®. If
reusing the filter, it must be
reconnected in the same
direction. Figure 4
3. Remove the red tube
(if applicable) quick-
connector from the
Phasitron® body. Figure 4a
4. If present, remove the
antibacterial filter from the
red tubing either side. Do
not wash. Figure 5
• continued on page 6
4
3
5
4a
