Perfect Flame 730-0335 - Caster Assembly

Take out bottom panel and four caster from the carton, Use 16 pcs of 1/4” X
12mm truss head screws and 16 pcs of 1/4” split locks (Pack C) to lock two
casters which in the right of bottom panel and two casters with brake which in the
left of bottom panel as shown figure below.
Pack C
CASTER ASSEMBLY
7
