Gemini 105Mc Owner’s Manual
19Copyright © 2004 Performance Cruising Inc.
Wiring Code
The standard code for 12-volt is red positive and
black negative. Unfortunately the boat cable sup-
plied sometimes comes red and black and some-
times white and black. We have chosen:
BLACK = NEGATIVE
RED OR WHITE = POSITIVE
Note that the color coding is different to shore
power where black is live and white neutral.
The European system is different and electronic
equipment that comes from Europe has the code:
BROWN = POSITIVE
BLUE = NEGATIVE
Switch Panel
The switches on the two 12-volt panels are also
circuit breakers and vary from 5 amp to 20 amp.
See table below.
VHF Radio
The VHF is recessed into the switch panel above the
12-volt panel. Consult the included owner’s manual
for information on operation.
Switch
Rating (amps) Purpose
Compass Light 5 Red light to illuminate compass at night
Masthead Lights 10 For sailing at night— 25 watt tri-color masthead light
Anchor Light 5 For anchoring—10 watt masthead light
Instruments 5 Backlight for TriData, AutoHeml, and instrument panel
Fans 15 Optional Fans — Includes through-flow refrigerator fan
Shower Pump 15 Also operates port and starboard bilge pumps
Deck Lights 10
Cabin Lights 20 Includes both fluorescent and incandescent
VHF 15
Gas Valve 20 Turns power on/off to Xintec Propane Monitor
Stereo/TV 15 Turns power on/off to AM/FM Radio / CD Player
Spare 20
Heater 20 Optional heater
Running Lights 5 For motoring at night
Stereo AM/FM/CD
The Gemini 105Mc now comes standard with an
AM/FM stereo CD player with two speakers mounted
on the main bulkhead. Consult the included owner’s
manual for information on operation.
Cabin Lights
The Gemini has three (3) fluorescent lights in the
main cabin over the galley, navigation station, and
saloon table. The fluorescent bulbs take an ex-
tremely low power draw and are intended as task
lighting. Each light draws 1/3 amps. Note that fluo-
rescent lighting is known to sometimes interfere with
VHF reception. Turning off the light corrects VHF
reception issues.
There are also six (6) 12-volt incandescent dome
lights, each located in the head, master bedroom,
each aft cabin, over the refrigerator and in the cock-
pit. Each light draws 1 amps. Red bulbs can be in-
stalled to maintain good night-vision.
Replacing Light Bulbs
Individual bulb specifications are subject to change.
When replacing a bulb, always remember to have the
original bulb with you when buying a replacement.
Related Topics:
See Mast Wiring on following page.
12 Volt Power
