Performax COMPACT PX12 LITHIUM-ION User Manual

28
Key #
Part #
Part Name
Quantity
21
3010080007
Housing
1
22
1070060003
Battery pack
1
23
1180060006
Pole plate
1
24
1039040003
Motor
1
25
2030220003
Motor flange
1
26
4020020019
Screw M3X6
2
27
4010010060
608 bearing
1
28
2040110015
Motor gear
1
29
4020010001
Screw M4X8
2
30
2030160003
Bearing clamp
1
31
4020020009
Screw M4X6
3
32
4010010058
6002 bearing
1
33
2020010015
Gear box
1
34
4020010005
Screw M4X16
4
35
2030090006
Retaining ring
1
36
2050060026
Spring
1
37
3120040021
Safety switch lock
1
38
3010080007
Housing
1
39
3160060021
LED cover
1
40
4080060001
SØ5 Steel ball
1
41
4080040001
SØ4 Steel ball
1
42
4030010034
Screw ST2.9X16
5
43
4030010130
Screw ST2.9X25
2
44
4030010127
Screw ST2.5X12
2
PARTS LIST
