MULTIPROP System
Instructions for Assembly and Use – Standard Configuration
Overview
Accessories
3 Base MP 50
3.1 Head plate
3.2 Clamping claw
3.3 Centering pin
4 Tilting Base MKF
4.1 Head plate
4.2 Clamping claw
4.3 Centering pin
4.4 Rotary wing
5 Tilting Forkhead MKK
5.1 Base plate
5.2 Clamping claw
5.3 Centering pin
5.4 Rotary wing
6 MULTIPROP Strap U100 – U140
6.1 Suspension fastening
6.2 Plate
6.3 Hex. bolt M16
6.4 Hex. nut M16, SW 24
7 Connector MPV-2
7. 1 Clamping lever
7. 2 Clamping jaws
7. 3 Centering pin
8 MULTIPROP Bolt with Nut
8.1 Bolt M12
8.2 Nut M12
9 Compression Brace Head MP/SRU
9.1 Fitting Pin 21 with Cotter Pin
3.1
3.2
3.3
5.4
5.3
5.1
5.2
7. 2
7. 3
7. 1
4.1
4.2
4.3
4.4
6.3
6.4
6.2
6.1
8.1
9.1
8.2
