MULTIPROP Single Props and System
43
Item no. Weight kg
027296 6,220 Tilting Base MKF
For use on inclined assembly areas.
Can be pivoted by 3° in all directions.
With clamped quick-release fastener.
Technical Data
Maximum permissible load 60 kN.
m
a
x
2
2
0
140
m
in
1
2
0
8
0
1
5
0
38Ø
Ø12,5
027297 8,730 Tilting Forkhead MKK
For tilt-resistant support of one or two GT 24
or VT 20 Girders. Can be pivoted by 3° in all
directions. With clamped quick-release fastener.
Technical Data
Separate design information on request.
1
9
5
m
in
1
2
0
170
240
85
155
80
150
Ø12,5
Ø6,5
m
a
x
2
2
0
027310 8,900 Base MP 50
For use with slab props with an end plate thick-
ness of 6 – 10 mm. With clamped quick-release
fastener.
Note
Permissible load: see PERI Design Tables.
5
0
0
89Ø
2
0
0
150
8
0
Ø12,5Ø42
022027 3,600 Wing Nut Spanner HD
For easy release of the Head Spindle HDK 45, the
Head Spindle TR 110-80/55 and the MULTIPROP
slab prop.
983
Ø38
AuV MULTIPROP EX.indb 43 07.01.16 11:58
