MULTIPROP Single Props and System
48
Item no. Weight kg
108339 0,203 Quick Strap MPB 24/GT 24
For assembly of GT 24 Girders on the Alu Beam
MPB 24.
8
0
6
8
70
6
7
Ø7
Ø5
018280 1,000
Accessories
Double Head Nail, L = 65 mm
107348 9,590 Coupling MPB 24
For connecting the Alu Beam MPB 24.
950
Ø21
1
2
9
48
105400
104031
018060
0,330
0,462
0,030
Accessories
Pin Ø 20 x 140, galv.
Fitting Pin Ø 21 x 120
Cotter Pin 4/1, galv.
079300
079360
079420
079480
079540
079600
24,000
28,800
33,700
38,500
43,300
48,100
Alu Beams MPB 24
Alu Beam MPB 24 L = 3.00 m
Alu Beam MPB 24 L = 3.60 m
Alu Beam MPB 24 L = 4.20 m
Alu Beam MPB 24 L = 4.80 m
Alu Beam MPB 24 L = 5.40 m
Alu Beam MPB 24 L = 6.00 m
Aluminium main beam for the MULTIPROP
system.
L
2998
3598
4198
4798
5398
5998
Technical Data
perm. Q = 50 kN
perm. A = 80 kN
perm. M = 15 kNm
L
80
2
4
0
