Perkin-Elmer Lambda 365 - Page 10

09931251D
10
2. Select the Calibration tab in the Multicell window. The following dialog box will appear.
3. The functions of the Multicell Calibration are shown as follows.
Command Function
MultiCell Position Show saved steps about each cell position of the Multi-Cell.
Multicell Move
Used for moving Multi-Cell position as clicking buttons
.
Used for moving Multi-Cell position using
buttons by
entered step.
Multicell Calibration Used to perform the Multi-Cell calibration.
Stop Used to stop the Multi-Cell calibration.
Save Result Used to save the calibrated result.
Reset Multicell Used to move to ‘0’ step of Multi-Cell position.
4. Click on Reset Multicell to format the Multi-Cell steps. Click OK.
