Illustration 29 g06277437
Typical example
(18) Secondary speed/timing sensor (19) Starting motor (20) Barometric pressure sensor
A turbocharge outlet temperature sensor (not shown)
will be installed within the exhaust outlet system.
38 M0090743
Operation Section
Sensors and Electrical Components
