i03995972
Maintenance Section
Refill Capacities
Refill Capacities
Lubrication System
The refill capacities for the engine crankcase reflect
the approximate capacity of the crankcase or sump
plus standard oil filters. Auxiliary oil filter systems will
require additional oil. Refer to the OEM specifications
for the capacity of the auxiliary oil filter. Refer to the
Operation and Maintenance Manual, “Maintenance
Section” for more information on Lubricant
Specifications.
Table 7
Engine
Refill Capacities
Compartment or System
Minimum Maximum
Crankcase Oil Sump
(1)
13.5 L
(3.56 US gal)
16.5 L
(4.36 US gal)
(1)
These values are the approximate capacities for the crankcase
oil sump (aluminum) which includes the standard factory in-
stalled oil filters. Engines with auxiliary oil filters will require ad-
ditional oil. Refer to the OEM specifications for the capacity of
the auxiliary oil filter. The design of the oil pan can change the
oil capacity of the oil pan.
Cooling System
Refer to the OEM specifications for the External
System capacity. This capacity information will be
needed in order to determine the amount of coolant/
antifreeze that is required for the Total Cooling
System.
Table 8
Engine
Refill Capacities
Compartment or System
Liters
Engine Only
15 L
(3.96 US gal)
External System Per OEM
(1)
(continued)
(Table 8, contd)
(1)
The External System includes a radiator or an expansion tank
with the following components: heat exchanger and piping. Re-
fer to the OEM specifications. Enter the value for the capacity
of the External System in this row.
i07074302
Fluid Recommendations
(General Fuel Information)
• Glossary
• ISO International Standards Organization
• ASTM American Society for Testing and
Materials
• HFRR High Frequency Reciprocating Rig
for Lubricity testing of diesel fuels
• FAME Fatty Acid Methyl Esters
• CFR Co-ordinating Fuel Research
• ULSD Ultra Low Sulfur Diesel
• RME Rape Methyl Ester
• SME Soy Methyl Ester
• EPA Environmental Protection Agency of
the United States
• PPM Parts Per Million
• DPF Diesel Particulate Filter
• v/v (volume of solute)/(volume of solution)
• CFPP Cold Filter Plugging Point
• BTL Biomass to liquid
• GTL Gas to liquid
• CTL Coal to liquid
• HVO Hydrotreated Vegetable Oil
General Information
NOTICE
Every attempt is made to provide accurate, up-to-
date information. By use of this document you agree
that Perkins Engines Company Limited is not respon-
sible for errors or omissions.
SEBU8601-04
73
Maintenance Section
Refill Capacities
