i03552521
Features and Controls
Monitoring System
(Engine)
Table 2
Warning Lamp
Shutdown
Lamp
Lamp Status Description of Lamp Status Engine Status
ON ON
Lamp check When the engine start switch is turned to the “ON” posi-
tion both lamps will illuminate for 2 seconds only.
The engine has not been
started.
OFF OFF
No faults There are no active diagnostic faults. The engine is running
normally.
ON OFF
Active diagnos-
tic fault
An active diagnostic fault has been detected. The engine is running
normally.
ON FLASHING
Active diagnos-
tic fault
A serious active diagnostic fault has been detected and
an engine derate has been invoked.
The engine is running but the
engine has been derated.
FLASHING OFF
Derate and
warning
One or more of the engine protection values has been
exceeded.
The engine is running but the
engine has been derated.
FLASHING ON
Engine
shutdown
One or more of the engine protection values has been ex-
ceeded or a serious active diagnostic fault has been
detected.
The engine is shutdown or
shutdown is imminent.
i03979949
Monitoring System
(Engine)
If the Shutdown mode has been selected and the
warning indicator activates, engine shutdown
may take as little as 20 seconds from the time the
warning indicator is activated. Depending on the
application, special precautions should be taken
to avoid personal injury. The engine can be re-
started following shutdown for emergency ma-
neuvers, if necessary.
NOTICE
The Engine Monitoring System is not a guarantee
against catastrophic failures. Programmed delays
and derate schedules are designed to minimize false
alarms and provide time for the operator to stop the
engine.
The following parameters are monitored:
• Coolant temperature
• Intake manifold air temperature
• Intake manifold air pressure
• Oil pressure
• Pressure in the fuel rail
• Fuel temperature
• Fuel filter differential pressure
• Water in fuel
• Engine speed/timing
• Atmospheric pressure (Barometric pressure)
• The Inlet pressure and outlet pressure of the NOx
reduction system
• The differential pressure within the NOx reduction
system
• Temperature of the NOx reduction system
• The amount of soot in the Diesel particulate filter
38
SEBU8601-04
Operation Section
Features and Controls
