1. Before the engine is started, move the throttle
lever to the 30 PERCENT OPEN position.
NOTICE
Do not operate the glow plugs for more than 30 sec-
onds at one time. Damage to the glow plugs could
occur.
2. Turn the engine start switch to the HEAT position.
Hold the engine start switch in the HEAT position
for 6 seconds until the glow plug indicator light
illuminates. This will activate the glow plugs and
aid in the starting of the engine.
NOTICE
Do not crank the engine for more than 30 seconds.
Allow the electric starting motor to cool for two mi-
nutes before cranking the engine again.
3. While the glow plug indicator light is illuminated,
turn the engine start switch to the START position
and crank the engine.
4. When the engine starts, release the engine start
switch.
5. Slowly move the throttle lever to the low idle
position and allow the engine to idle. Refer to the
Operation and Maintenance Manual, “After
Starting Engine” topic.
Note: If the glow plug indicator light illuminates
rapidly for 2 to 3 seconds, or if the glow plug indicator
light fails to illuminate, a malfunction exists in the cold
start system. Do not use ether or other starting fluids
to start the engine.
6. If the engine does not start, release the engine
start switch and allow the electric starting motor to
cool. Then, repeat steps 2 through step 5.
7. Turn the engine start switch to the OFF position in
order to stop the engine.
i02177935
Starting with Jump Start
Cables
Improper jump start cable connections can cause
an explosion resulting in personal injury.
Prevent sparks near the batteries. Sparks could
cause vapors to explode. Do not allow jump start
cable ends to contact each other or the engine.
Note: If it is possible, first diagnose the reason for the
starting failure. Make any necessary repairs. If the
engine will not start only due to the condition of the
battery, either charge the battery, or start the engine
with jump start cables. The condition of the battery
can be rechecked after the engine has been switched
OFF.
NOTICE
Using a battery source with the same voltage as the
electric starting motor. Use ONLY equal voltage for
jump starting. The use of higher voltage will damage
the electrical system.
Do not reverse the battery cables. The alternator can
be damaged. Attach ground cable last and remove
first.
When using an external electrical source to start the
engine, turn the generator set control switch to the
“OFF” position. Turn all electrical accessories OFF
before attaching the jump start cables.
Ensure that the main power switch is in the OFF posi-
tion before attaching the jump start cables to the en-
gine being started.
1. Turn the start switch to the OFF position. Turn off
all the engine's accessories.
2. Connect one positive end of the jump start cable to
the positive cable terminal of the discharged
battery. Connect the other positive end of the jump
start cable to the positive cable terminal of the
electrical source.
3. Connect one negative end of the jump start cable
to the negative cable terminal of the electrical
source. Connect the other negative end of the
jump start cable to the engine block or to the
chassis ground. This procedure helps to prevent
potential sparks from igniting the combustible
gases that are produced by some batteries.
4. Start the engine.
5. Immediately after the stalled engine is started,
disconnect the jump start cables in reverse order.
After jump starting, the alternator may not be able to
fully recharge batteries that are severely discharged.
The batteries must be replaced or charged to the
correct voltage with a battery charger after the engine
is stopped. Many batteries which are considered
unusable are still rechargeable. Refer to Operation
and Maintenance Manual, “Battery - Replace” and
Testing and Adjusting Manual, “Battery - Test”.
32
SEBU7992-05
Operation Section
Starting with Jump Start Cables
