Perkins M185C - Page 30

Chapter 5 TPD1317e
Page 26
Sea water
pump
Connection for
32mm (1.25”) bore
hose
1.00” B.S.P.
skin tting
1.00” B.S.P. valve
giving straight through
ow
Sea Water Pump
Water line
32mm (1.25”) bore reinforced
exible suction hose
Valve
Note: Where possible mount the strainer so that the top is just above the waterline - to facilitate cleaning.
Figure 1 - Sea water intake system.
