Chapter 10 TPD1317e
Page 64
Caution: The hoses connecting the calorier to the engine are part of the closed engine cooling system.
Failure of a hose will lead to the engine overheating!
Figure 1b - Calorier ttings for M92B
Supply to
calorier
Return from
calorier
