TPD1317e Chapter 8
Page 55
Engine Controls
It is recommended that a Morse single lever system is used to control engine speed and gearbox
engagement.
8.1 M300Ti, and M265Ti Engines
These engines are equipped with an electric stop solenoid as standard, but a piano wire stop cable may also
be tted, as shown below.
Clamp for Morse A410
stop cable inner
Anchor for Morse A410
stop cable assembly
Anchor for Morse 33C cable to
operate speed selector lever
Run
Stop
Stop
lever
Full
speed
Idle
Speed
selector
lever
