Getting to Know Your IOLAN
Rack Mount
This section describes the basic components of all rack mount IOLAN models. This example uses the
IOLAN SCS with dual Ethernet and dual AC power.
Console Port/LED View
Serial/Ethernet View
Note: The SCS16C DSFP model has two SFP slots.
Power ON/OFF
Server LEDs
Serial Activity
Console Port
Serial Ports
Dual Ethernet or SFP slots
PCI Card Faceplate
(SCS models only)
Dual AC Power
Reset
