16
2. Adjust the two upper poles to your desired height. Please note that
the two upper poles should be adjusted at the same time.
3. Insert the latches [05-B] into the holes nearest to the connecting
part of upper pole and lower pole, then tighten the knobs [05-A] to fix
the two upper poles in place.
05-B
05-B
05-A
05-A
860-00413-00 Rev02
