Phillips Screwdriver
(NOT lncluded)
5/32″ (4mm)
Secure the TV plate [09] to the upper pole [07]. Make sure the TV plate is leveled.
09
[Z-B]
[Z-A]
Step 6 Hang the TV on the TV Plate [09]
[Z-G]
[S]
Slightly loosen preassembled bolts [S] on both brackets.
15
