Perlesmith PSTVMC04 - Step 1: Attach TV Brackets to TV; Select TV Mounting Bolts; Spacer and Bolt Configurations

1-1 Select TV Bolts
Step 1 Attach TV Brackets to TV
M6
M8
M4
Hand thread bolts into the threaded inserts on the back of your TV to determine which bolt (M4,
M6 or M8) to use. A minimum of 4-5 turns into the threading is required. Do not turn past the
bottom of the hole.
1-2 Spacer and Bolt Configurations
Bump
See Option C
Cables
See Option D
Recessed Holes
See Option E
Curved TV
See Option B
Flat Back TV
See Option A
