Perlesmith PSTVMC06 - Spacers and Bolt Selection; Spacers [if needed]; Select TV Bolts

Only one bolt size fits your TV.
M6M4 M8
Bolt length:Verify adequate thread engagement with bolts or bolts/spacers combination.
We recommend thread engagement by at least 5 turns.
-Too short will not hold the TV.
-Too long will damage the TV.
Too Short
Too Long
Correct Correct
Select TV Bolts
Please Note: The provided TV bolts meet most of today's TVs design. However, some
TVs require special bolts which may not be in the hardware bag. In this case we offer our
“PSUHP" Universal Hardware Kit which provides a large selection of bolts that can meet
the demand of older and unique applications.
Please Note: When using the spacers it is important to note that they can be used in
multi-layers (meaning stacked). If you have any difficulty understanding how to install the
TV bolts or spacers, please contact customer service at supportus@perlesmith.com (US) /
supportca@perlesmith.com (CA).
CAUTION: Ensure the TV brackets
10 are EQUALLY CENTERED on your
TV and securely fastened in place.
10
UP
Note:
Keep the arrow up.
TV9 x4
φ8.5x18x10mm
TV10 x4
φ8.5x18x22mm
TV8 x8
φ8.5x18x2.5mm
Spacers [if needed]
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16
