Perlesmith PSTVMC06 - Step 8 Secure the Brackets to the TV

Step 8
Secure the Brackets to the TV
Note: The bolts are shown in accordance with the actual size
M6
TV2 x4
M6 x 16mm
TV3 x4
M6 x 35mm
M4
TV1(01) x4
M4 x 12mm
TV1(02)x4
M4 x 30mm
M8
TV4x4
M8 x 25mm
TV5 x4
M8 x 50mm
X2
TV Bracket
10
Note: The washers and spacers are shown in accordance with the actual size
TV6x4
Washer
TV7 x4
D8 Steel Washer
