Perlesmith PSTVMC06 - Step 7 Secure the Cable Clip

Step 7
13
B
F
Secure the Cable Clip [13] to the Connecting Parts
of the Poles
5/32 in (4mm)
Small Allen Key
5/32 in (4mm)
Small Allen Key
F
x2
x4
x1
Cable Clip
13
B
M6x12mm
Bolt
Small Allen Key
