Step 10
G
Insert the safety locks [G] into the upward facing hooks at the midway to
lower part of the TV bracket. Please note this is where the lower part of
the TV bracket meets the lower part of TV plate. Then tighten the bolts of
the safety lock [G] until the bolts touch the TV plate.
Secure TV to TV Plate [09]
Note: Please note that there is no holes on the TV plate.
x2
Safety Lock
G
