Perlesmith PSTVMC06 - Step 11 Secure the Shelf to the Pole

5/32 in (4mm)
Small Allen Key
Step 11
Secure the shelf [11] to the pole using connecting plate [12], bolts [E] and
Allen key [F].
Secure the Shelf [11] to the Pole
You may need assis-
tance with this step.
E
F
12
11
Shelf
x1
x1
x2
x1
Connecting Plate
11
12
M5x55mm
Bolt
E
5/32 in (4mm)
Small Allen Key
F
