Perlesmith PSTVMC06 - Step 2 Screw the Casters; Step 3 Secure the Lower Pole

06
06
A
H
01
Step 2
Step 3
04
02
03
I
Screw the Casters [04] to the Short Square Tube [03] and
Long Square Tube [02]
Secure the Lower Pole [06] to the Center of the Tube
Connector [01]
15/32 in (12mm)
Wrench
Note: The groove on the lower pole [06] should be
aligned with the groove on the tube connector [01].
5/16 in (8mm)
Large Allen Key
Lock Unlock
x4
Caster
04
x1
Wrench
10mm
12mm
I
A
5/16 in (8mm)
Large Allen Key
H
x1
x1
x1
Lower Pole
06
M10x35mm
Bolt
Washer
D10x30x2.5mm
Large Allen Key
