Perlesmith PSTVMCO4 - Step 4 Attach Shelf to Pole

Use Tool Kit(21)
Use Tool Kit(21)
16
15
14
12
13
5
240mm
14
12
Use Tool Kit(21)
Step 4 Attach Shelf To Pole
Attach shelf supports (15) to the shelf (14)
by using M6 nuts (16)
4.1
4.3
4.2
Attach shelf connecting plate (13) to the
pole (5) by using M6x10 bolts (12)
Attach shelf (14) to the shelf connecting
plate (13) by using M6x10 bolts (12)
