P3
(P) x1
Support Pillar
(Z) x1
Top Cover
(W) x4
Foot Pad
(R) x1
Gasket with
3 Holes
(Y) x1
Plastic Cover
(M) x1
TV Plate
(Q) x4
M6 Nut
(S) x4
M6x40mm
Bolt
(T) x4
D6.5 Washer
WARNING: This product contains small items that could be a choking
hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. Do not
use damaged or defective parts. lf you require replacement parts, contact our
customer service at supportus@perlesmith.com (US)/
supportca@perlesmith.com (CA).
• Please note: Not all hardware included in this package will be used.
(O) x1
Tempered Glass Base
Supplied Parts and Hardware
Supplied Parts and Hardware for Step 1
Supplied Parts and Hardware for Step 2
Note: The bolt is
shown in accordance
with the actual size
Note: The bolt is shown in
accordance with the actual size
(L) x3
M6x25mm Bolt
(V) x1
5/32in (4mm)
Allen Key
(V) x1
5/32in (4mm)
Allen Key
To Next Page
