Perlesmith PSTVS04 - Page 5

P4
(A) x4
M4x30mm
Bolt
(B) x4
M6x15mm
Bolt
(C) x4
M6x35mm
Bolt
(D) x4
M8x20mm
Bolt
(E) x4
M8x35mm
Bolt
(F) x4
M8x50mm
Bolt
(G) x4
Washer
(K) x2
Wire Clip
(H) x8
φ8.5x18x2.5mm
Spacer
(I) x4
φ8.5x18x10mm
Spacer
(J) x4
φ8.5x18x22mm
Spacer
(N) x2
TV Bracket
Note: The bolts and spacers are shown in accordance with the actual size
Supplied Part for Step 3
Supplied Parts and Hardware for Step 4
