Option B (For Round Back TV)
Option A (For Flat Back TV )
G
A/B/D
H/I
(If needed)
G
A/C/E/F
H/I/J
N
Alternate Spacer
Setups
Note: Keep
the arrow up
Note: Keep
the arrow up
Alternate
Spacer
Setups
CAUTION: Ensure the TV brackets
[N] are EQUALLY CENTERED on your
TV and securely fastened in place.
Please note: The bolt hole locations
on your TV may vary in accordance of
the manufacturers design of the TV. We
are only illustrating possible locations
of the bolt holes.
