Perlesmith PSTVS21 - Step 5 Attach TV to the TV Plate [04] and Manage the Wires

TV6
TV7
TV8/TV9/TV10
TV2/TV4/TV5
Alternate Spacer Setups
Option E
For cable interference or inset holes, use
spacers [TV8], [TV9] and [TV10] to create
extra space between the TV and TV brackets
TV brackets are three-height-adjustable.
You can choose the proper height.
The second
choice
The first
choice
The third
choice
Step 5 Attach TV to the TV Plate [04] and Manage the Wires
Alternate Spacer Setups
The spacers must be used with washers (TV7) to stop spacers from falling down.
01 02 03 04 05 06 07 08 09 10 11
