Perlesmith PSTVS21 - Page 9

TV6
TV7
TV8/TV9/TV10
TV2/TV4/TV5
Alternate Spacer Setups
TV6
TV7
TV8/TV9/TV10
TV2/TV4/TV5
Spacers may be necessary for 2 holes ONLY.
Option D (For TV with A “Bump”)
Option C (For Round Back TV)
The spacers must be used with washers (TV7)
to stop spacers from falling down.
The spacers must be used with washers (TV7) to stop spacers from falling down.
TV6
TV1
TV3
TV6
TV1
TV3
01 02 03 04 05 06 07 08 09 10 11
