TV6
TV7
TV8/TV9/TV10
TV2/TV4/TV5
TV7
Alternate Spacer Setups
05
CAUTION: Ensure the TV
brackets [05] are EQUALLY
CENTERED on your TV and
securely fastened in place.
Option A (For Flat Back TV)
Option B (For Flat Back TV)
UP
TV6
TV1
TV3
The spacers must be used with washers (TV7)
to stop spacers from falling down.
PLEASE NOTE: The bolt hole
locations on your TV may vary in
accordance of the manufactur-
ers design of the TV. We are
only illustrating possible loca-
tions of the bolt holes.
