Connect the support pillar [02] to tempered glass base [01]
Step 1-2
Place foot pads [F] to the painted side of the tempered glass base
[01] in the corners
Step 1-1
Step 1 Assemble the Base
Supplied Parts and Hardware for Step 5
F
01
D
C
B
I
Note：Kindly note that the tempered glass base is designed
to show the shiny glass side facing up
Attach the tempered glass base by using bolts [B], steel washers [D] and
plstic washers [C].
(G) x2
Safety Lock
You may need assistance with this step
Back Side
Front Side
02
03
01 02 03 04 05 06 07 08 09 10 11
