Perlesmith PSTVS21 - Step 2 Connect the TV Plate [04] to Support Pillar [02]

The First Choice
The Second Choice
The Third Choice
Note: There are three choices for
height adjustment. You can choose
your desired height position while
connecting the swivel component
[06] and TV plate [04] to support
pillar [02].
Step 2 Connect the TV Plate [04] to Support Pillar [02]
The First Choice The Second Choice The Third Choice
2-1
E1
06
2-2
I
Note: Make sure the bump of the TV
plate faces back side of the TV stand.
You may need assistance with this step
E2
04
I
Back Side
