1. Loosen the preassembled knob [T].
2. Adjust TV to your desired tilt angle.
3. Tighten the preassembled knob [T] to secure the TV in place.
T
T
Loosen Tighten
F2
Step 6 Adjustments
DO NOT over-loosen these four nuts when
adjusting the level angle to prevent the TV
from falling off.
CAUTION!
Allen Key
Level
Tilt
1.Loosen the bolt [F2] .
2.Level your TV.
3.Tighten the bolt [F2] to secure the
TV in place.
F2
12
