Commercial Back Bar Installation & Operation Manual
6
5. Loosely attached the four corners of the overlay
panel with the door frame with #10 x 3/4” wood
screws.
6. Make sure the overlay panel is aligned properly
with the door.
7. After alignment is satised, fasten down all screws
through the screw holes.
8. When re-installing the gasket, make sure the dart is
pressed inside the slot on the door frame. Start at
the four corners and rmly press your way inwards
Do not overtighten wood overlay
attachment screws, as this may
damage the factory supplied door frame.
