Electrical Diagram
PKD24B PARTS MANUAL Rev. 11.09 Page 14
PROBLEM LIKELY CAUSE SOLUTION
Rinse pump does not run Defective rinse pump motor Replace pump motor
P/N: 00416.00
Defective timer assembly
(Cam 6)
Replace timer assembly
*
P/N: 00408.80
Activating detergent primer
switch does not run pump
Defective sani/detergent primer
switch
Replace primer switch
P/N: 03470.00
Defective detergent pump motor Replace pump motor
P/N: 00416.00
Activating sani primer
switch does not run pump
Defective sani/detergent primer
switch
Replace primer switch
P/N: 03470.00
Defective sani pump motor Replace pump motor
P/N: 00416.00
Activating rinse primer
switch does not run pump
Defective rinse primer switch Replace primer switch
P/N: 03470.00
Defective rinse pump motor Replace pump motor
P/N: 00416.00
Counter does not
increment
Defective counter Replace counter
P/N: 03408.50
Defective timer assembly
(Cam 3)
Replace timer assembly*
P/N: 00408.80
Running light does not
light while cycle runs
Defective cycle light Replace running light (green)
P/N: 00476.00
Power light does not light
but machine runs
Defective power light Replace power light (red)
P/N: 00406.00
Wash tank temperature
gauge displays wrong
temperature
Defective temperature gauge Replace temperature gauge
P/N: 03202.00
Delime switch does not
activate pump motor
Defective delime switch Replace delime switch
P/N: 00475.30
Defective pump motor Replace pump motor
P/N: 00201.00
*The timer assembly motor (P/N: 00501.00) or micro switches (P/N: 00411.00) can be replaced
independently if that is the only component that has failed.
