PKD24B INSTALLATION & OPERATION MANUAL Rev. 11.09 Page
2
1. Specifications
1.1. PKD24B
WATER CONSUMPTION
PER RACK 1.7 GAL. 6.44 L
PER HOUR 40.8 GAL. 154.4 L
OPERATING CYCLE
WASH TIME-SEC 57 57
RINSE TIME-SEC
48
48
DWELL TIME-SEC 15 15
TOTAL CYCLE 2 MIN. 2 MIN.
OPERATING CAPACITY
RACKS PER HOUR 30 30
WASH TANK CAPACITY 1.7 GAL. 6.44 L
PUMP CAPACITY 35 GPM 132.5 LPM
WATER REQUIREMENTS 140°F 60°C
WATER INLET ½” 1.27cm
DRAIN CONNECTION 1” 2.54 cm
CYCLE TEMPERATURES
WASH-°F (Min) 140 60°C
FRAME DIMENSIONS
DEPTH
23 ½”
59.69 cm
WIDTH 24” 60.96 cm
PKD24B HEIGHT
30”
76.2 cm
PKD24B MAX CLEARANCE FOR
GLASSES
12 ¼” 31.11 cm
ELECTRICAL*
115 VAC
15.8 AMPS
SUSTAINER HEATER
(Not Booster Heater)
0.8 kW
WASH PUMP MOTOR 13.4 AMPS
*
MUST CONNECT TO DEDICATED 20 AMP SUPPLY CIRCUIT.
COMPLIANCE WITH LOCAL ELECTRICAL CODES MUST BE FOLLOWED.
SHIPPING WEIGHT
PKD24B (Approximate) 190# 86.2 kg
METRIC
EQUIVALENT
