5
Programming the Alarm Panel
The alarm panel must be programmed with:
Contact ID
Tone / DTMF dialling
Four digit Panel ID number
8 digit telephone number
Arm & Disarm reporting must be enabled. (This is required for the Pocket
Secure App)
Trigger an alarm event or test report from the alarm panel. The panel dialler will
seize the line and send data on ‗R‘ & ‗T‘. The ―CID‖ LED = [Green - Blinking].
When a valid Contact ID event is sent from the alarm panel the
‗CID‘ LED = [Green - Steady On].
Ping the PM24 using Atlas to verify status of installation.
Antenna Installation
Antennas can have their performance maximised using a ―Ground Plane‖, any
metal mounting surface will suffice. Please use the supplied ―Ground Plane‖ plate
if you are not mounting this antenna on a metal surface. A significant reduction in
performance occurs if an antenna does not have an adequate ground plane.
If signal strength is low, a high gain aerial may be required.
The Permaconn Part N# is ‗ANTH3G
Extension cables for the high gain aerial are available
Length in Meters Part N#
3 EXT3
5 EXT5
10 EXT10
NB: Do not exceed 10 meters.
PM24 Installation Manual v1.1 RDCCO_2204_E_IN
