F3 Corpus
Preparing for use
Setting armrest rotation in end position
Figure 127. Adjusting the armrest rotation end position.
The end positions are set by moving one or two screws between
three different positions underneath the armrest. Fold the armrests
up to get easier access to the screws.
1. Fold up the armrest.
2. Remove the screws underneath the armrest.
3. Insert the screws in the preferred positions.
4. Fold down the armrest.
4.1.4.2 Armrest height
The following tools are necessary for this task:
• 1 Allen key, 5 mm.
The height of the armrest is adjustable for optimal comfort. Refer to
the scale on the centre of the backrest to see the current height of
the armrest.
