F3 Corpus
Preparing for use
4.1.6 Footplates
WARNING!
Risk of injury while adjusting footplates
Do not place any weight or load on the footplates while adjusting the
footplates.
4.1.6.1 Footplate height
Figure 135. Adjusting footplate height.
The height of the footplates is individually and steplessly adjustable.
They are secured using the two outer locking screws.
1. Remove the leg support cover.
2. Undo the footplates’ locking screws.
3. Adjust the footplates to the required height and secure by
tightening the locking screws.
4. Check that the footplates are fully secured.
5. Replace the leg support cover.
151
