Getting to know your wheelchair
Battery indicator
Figure 42. Battery indicator.
This displays available battery charge and can be used to alert the
user of the status of the battery.
• Steady light: everything is in order.
• Flashing slowly: the control system is functioning correctly, but
the battery should be charged as soon as possible.
• Stepping up: the wheelchair batteries are being charged. The
wheelchair cannot be driven until the charger is disconnected and
the control system is switched off and on again.
Maximum speed indicator
Figure 43. Maximum speed indicator.
This displays the current maximum speed setting.
The maximum speed setting is adjusted using the speed paddle.
77
