F3 Corpus
Getting to know your wheelchair
Backlight
The following section describes submenus related to Backlight.
Backlight This sets the backlight on the screen. It can be set
between 0% and 100%.
Auto Backlight The joystick module contains an ambient light
sensor to automatically adjust the screen
brightness. The programmable options are Off or
On. When set to On, the display adjusts the
screen brightness based on the light sensor
reading. When set to Off, the screen brightness
will not change with changes in light intensity.
Backlight Time This adjusts the period of time the backlight will
remain active once no further instructions are
received from an input device. It is adjustable
between 0 and 240 seconds.
Bluetooth®
Applies to control panels equipped with integrated Bluetooth®.
Nudging the joystick to the right will enter a submenu to configure
the Bluetooth® mode screen. Refer to the Bluetooth® mode
chapter for more details; see page 85.
82
